Lynx Pro Audio RS4-3000 4 x 750W Power Amplifier

£1,188.00

A range of lightweight 2 or 4 channel power amplifiers designed to meet the demands of installation or touring. The RS Series is based on an inverted mono-block approach offering an all-in-one power module that contains the entire amplifier assembly. The upside-down design reduces dust build-up to maximise cooling efficiency. The latest generation QuantaPulse™ switching power supply allows to reach a new level of refined sensing and control of the power flow.

A range of lightweight 2 or 4 channel power amplifiers designed to meet the demands of installation or touring. The RS Series is based on an inverted mono-block approach offering an all-in-one power module that contains the entire amplifier assembly. The upside-down design reduces dust build-up to maximise cooling efficiency. The latest generation QuantaPulse™ switching power supply allows to reach a new level of refined sensing and control of the power flow.

    • Class H design offers market leading audio quality and high efficiency

    • 2 or 4 Channel models from 1000W up to 4000W

    • Ultra-lightweight 6kg, compact package only 25cm deep

    • Latest generation QuantaPulse™ switch mode power supply

    • Power Management System (PMS™) and Clip Limiter (ICL™)

    • Upside down internal design to avoid fan dust accumulation

    • Industry standard Neutrik® XLR and SpeakON® connectors

    • Comprehensive protection set (ICL, PMS, SSP, turn-on, Temp, DC)

    • Detented sealed potentiometers

    • Dual or bridge mode operation

    • Temperature controlled, rear to front cooling fan

    • Power output - Stereo 8Ω: 4 x 450Wrms

    • Power output - Stereo 4Ω: 4 x 700Wrms

    • Power output - Stereo 2Ω: 4 x 750Wrms

    • Power output - Bridge 8Ω: 2 x 1400Wrms

    • Power output - Bridge 4Ω: 2 x 1500Wrms

    • Frequency response: 20Hz-20kHz

    • Sensitivity: 1.5V

    • Power supply: 170V-265V AC, 50/60Hz

    • Dimensions: 483 x 88.9 x 254mm

    • Weight: 6kg

  • Barcode / EAN - 0759478552992

    Packed Dims (H x W x D) - 16 x 56 x 38cm

    Packed Weight - 7.3kg

    Outer Carton Quantity - 1

    Commodity Code - 8518400090

    Country Of Origin - ES

  • MANUAL

    DATA SHEET
